Typical applications:

• Jacketed reactor vessels

• Large rotary evaporators

• Reaction calorimetry

• Fermentation

• Analytical instrumentation cooling

技术参数：

Temperature Range： -40 to 150 °C

Cooling Capacity at 20 °C (50 Hz / 60 Hz)： 1.2 kW

Heating Capacity (230 V - 50 Hz / 208 V - 60 Hz)：2 kW / 1.6 kW

Temperature stability： +/- 0.01 K

Pump Performance (with silicon oil)：

Maximum Pump Pressure (bar)：1，2

Maximum Flow Rate：20 l/min

Pump Performance (with water)

Maximum Pump Pressure (bar)：1，5

Maximum Flow Rate：25 l/min

Electrical Performance

Power Requirements： 230 V / 50 Hz - 1 phase，

Maximum Current： 16 A

Communication：RS232， RS485

Display： 128 x 64 pixel

主要特点：

Extremely Fast Cooling and Heating with Precise Temperature

Easy to Operate

Programmable in

seven languages， the controller can store

10 ramping programs with 30 segments， saving you valuable programming time.

Adaptable to Meet Application NeedsDynaMax units cover a wide temperature range and thus are suitable for a variety of

applications. The systems feature a modular

design for even greater flexibility. You can configure the system for a specific application

and purchase only the options that you need.
