品牌

SETCAS

产地

美国

Slot-Die Head Coating Width

50 mm

Slot-Die Shim Thickness

100 μm

Hotplate Temperature

120 °C

Stage Travel Length

100 mm

Coating thickness range

1-1000 μm

Minimum Stage Speed

100 μm.s^-1

Maximum Stage Speed

50 mm s^-1

Mini Syringe Speed

12 μm.s^-1

Max Syringe Speed

5 mm.s^-1

 Head to Substrate Travel Distance

13 mm

Power Supply

DC 24 V, 6.2 A, via 100-240v 50/60Hz power adapter

Dimensions

Depth x Width x Height (360 mm x 280 mm x 190 mm)

Shipping Weight

< 10 kg
