产品价格
| 产品编号 | 品牌 | 包装单位 | 单价(元) | 现货 |
| 3087495 | Sigma-Aldrich | 5 G | 1530 | 请咨询 |
| 3538210 | 1-Material | 1G | 2470 | 请咨询 |
| 3538210 | 1-Material | 2g | 3750 | 请咨询 |
| 3538210 | 1-Material | 5g | 6000 | 请咨询 |
结构式
 |
基本信息
| Empirical Formula【经验(实验)分子式】 | C24H21CoF18N9P3 |
| Molecular weight | 929.31 |
| PubChem Substance ID【PubChem化学物质编号】 | 329768924 |
| NACRES | NA.23 |
| General description【一般描述】 | FK 102 Co(III) PF6 salt (FK 102) is a cobalt based p type dopant that is used in chemical doping of triarylamine based hole conductors. It can be used in the fabrication of dye sensitized solar cells (DSSCs). It has a redox potential of 1.06 V and shows no absorption in the visible region. |
| Application【应用】 | Use this cobalt complexes to increase photovoltages of liquid electrolyte cells substantially or to achieve ultrahigh performance with solid state photovoltaic devices. FK102 cobalt complexes offer guaranteed performance, high reproducibility, consistent results and are of highest purity. In comparison to triiodide-based redox electrolytes, cobalt complexes in general increase photovoltages and particularly at lower light levels (e.g. for indoor applications), significantly increase device power output. Recommended use: In liquid-based electrolytes: typically 0.15-0.2 M of Co(II) and ca. 0.05 M Co(II) In solid-state photovoltaic cells: up to 10 weight % added to the hole transport material system. |
| Legal Information【法律信息】 | Product of Greatcell Solar® Greatcell Solar is a registered trademark of Greatcell Solar |
产品性质
| Quality Level【质量水平】 | 100 |
| description【描述】 | Carbon: 28.5%-30.1% Nitrogen: 12.5% - 13.2% |
| Assay【测定】 | >98% |
| form【形式】 | powder |
| SMILES string | N1(C2=NC=CC=C2)N=CC=C1.C3(N4C=CC=N4)=CC=CC=N3.C5(N6C=CC=N6)=CC=CC=N5.C |
| packaging【包装】 | 5 g in poly bottle |
安全信息
| Pictograms【象形图】 | GHS07 |
| Signal word【警示用语：】 | Warning |
| Hazard Statements | H315 - H317 - H319 - H335 |
| Precautionary Statements | P280 - P302 + P352 - P305 + P351 + P338 |
| Hazard Classifications【危险分类】 | Eye Irrit. 2 - Skin Irrit. 2 - Skin Sens. 1 - STOT SE 3 |
| Target Organs【靶器官】 | Respiratory system |
| Storage Class Code【储存分类代码】 | 11 - Combustible Solids |
| WGK | WGK 3 |
