信号源特点：快速上升时间，低抖动，高电压，任意波形能力或光输出；
  种种优势使得BNC信号源在需要精确触发的领域如科学研究、国防科技及医学研究等发挥着巨大的运用功效

  Features

  •  < 200 μs frequency switching time

  •  Very low SSB phase noise: -108 dBc/Hz at 10 GHz and 20 kHz offset

  •  Comprehensive AM， low-distortion， wideband

  •  DCFM and high-speed pulse modulation for testing all types of receivers

  •  LAN/USB/GPIB (optional) remote control with SCPI

  •  1999 command set

  •  Input for USB power sensor

  •  Powerful trigger and sweeping modes

  Applications

  •  R&D low noise signal source

  •  Production testing (industry-leading switching times; high dynamic range)

  •  Service and maintenance (battery operation)

  •  Signal simulation (radar， WiMax， UWB)

  •  Aerospace and defense (pulse modulator， chirps)

  Options

  •  RM: 19" Rackmount Kit

  •  B3: Internal battery

  •  TP: 3U 19'' desktop included with touch display control

  •  HP: Extended maximum output power (needs option TP)

  •  PE: Power range extension to -90 dBm

  •  PE3: Power range extension to -130 dBm

  •  GPIB: GPIB interface added

  •  WE3: Warranty extension to 3 years

  •  WE5: Warranty extension to 5 years
